HGLRC M3 20A 4in1 ESC 20x20 10 Pack
HGLRC M3 20A 4in1 ESC 20x20 10 Pack from Cyclone FPV
This ESC can be used with any FC stack but was designed for the HGLRC F420 stack featuring the HGLRC F4 M3 20x20 Flight Controller.
Model: HGLRC DShot20A BLHeli_S 2-4S 4-in-1 ESC
- Input Voltage: 2-4S Lipo battery
- Constant Current: 20A-4S
- Peak Current: 25A/10S
- BEC Ouput: NO
- Firmware: BLHELI_S
- Size: 30x30mm (main board)
- 35x38mm (including pad)
- Installing Hole:20x20mm,M3
- Weight: 8.2g
- MOS Tube: TOP QUALITY MOSFET
- Protocol: DSHOT600/300/150/Oneshot125/42,MultiShotDamped mode
- This package contains the ESC only. There is not flight controller, mounting hardware, wire harnesses, or mounting hardware.
