FrSky SR6 SR8 Pro and SR10 Pro Receivers from Cyclone FPV

The Archer SR6, SR8 Pro, and SR10 Pro are gyro-stabilized receivers with a built-in 3-axis gyroscope and 3-axis accelerometer, they have 6 high-precision PWM channel outputs (SR6),  8 high-precision PWM channel outputs (SR8 Pro), and 10 high-precision PWM channel outputs (SR10 Pro) and feature multiple flight modes and configuration methods. They support full-range signal strength with dual detachable antennas it guarantees optimal antenna reception and maximum range. In addition to all this, the SR6, SR8 Pro, and SR10 Pro can also be used as redundancy receivers along with any other FrSky ACCESS capable receiver equipped with an SBUS port.

All of the Archer receivers are hyper-matched with the ACCESS protocol. They not only feature wireless firmware upgrades and increased range and telemetry performance, the SR6, SR8 Pro, and SR10 Pro now support more functions like configurable telemetry power, S.Port/F.Port/F.Port 2.0 switching and FLR output. Additional valuable features are under development to unlock the true potential of the ACCESS protocol.

SR6 SR8 Pro SR10 Pro Features:

  • ACCESS protocol with Over The Air (OTA)
  • Built-in 3-axis gyroscope and 3-axis accelerometer sensor
  • Multiple flight modes and configuration methods (LUA & Freelink)
  • Supports signal redundancy (SBUS In)
  • Full control range with telemetry
  • S.Port / F.Port / F.Port 2.0
  • Anti-interference in spark-ignition (SR8 Pro / SR10 Pro Only)
  • External battery / device voltage detection

SR6 Specifications:

  • Dimension: 47.5*20.5*11mm (L*W*H)
  • Weight: 13g
  • 16/24 Configurable SBUS Channels
  • 6 High-precision PWM Channels
  • Operating Voltage Range: 3.5 -10V
  • Operating Current: <60mA@5V
  • Control Range: Full range* with telemetry
  • (*Full Range: >2km, range may vary based on local conditions.)
  • Voltage Measurement Range via AIN2 (External device): 0-3.3V
  • Compatibility: All FrSky ACCESS transmitters

SR8 Pro Specifications:

  • Dimension: 47*26*15mm (L*W*H)
  • Weight: 15g
  • 16/24 Configurable SBUS Channels
  • 8 High-precision PWM Channels
  • Operating Voltage Range: 3.5 -10V
  • Operating Current: 55mA@5V
  • Control Range: Full range* with telemetry
  • (*Full Range: >2km, range may vary based on local conditions.)
  • Voltage Measurement Range via AIN2 (External device): 0-36V
  • Compatibility: All FrSky ACCESS transmitters

SR10 Pro Specifications:

  • Dimension: 48.5*33*17mm (L*W*H)
  • Weight: 23g
  • 16/24 Configurable SBUS Channels
  • 10 high-precision PWM Channels
  • Operating Voltage Range: 3.5 -10V
  • Operating Current: <60mA@5V
  • Control Range: Full range* with telemetry
    (*Full Range: >2km, range may vary based on local conditions.)
  • Voltage Measurement Range via AIN2 (External device): 0-36V
  • Compatibility: All FrSky ACCESS transmitters
